Attributes

Attributes describe the properties of entities or relationships. For example, a Customer entity might have attributes such as CustomerID, Name, and EmailAddress.

Multiple Relationship with Attributes

Attributes can be further classified based on their structure and value types:

Simple Attribute

A simple attribute has a single value that exists independently, such as Name or Age.

Composite Attribute

A composite attribute is made up of multiple components. For instance, a Name attribute might consist of FirstName and LastName.

Multi-valued Attribute

An attribute that can have multiple values for each entity. For example, an employee might have multiple PhoneNumbers.

Derived Attribute

A derived attribute is calculated or inferred from other attributes. For instance, an employee’s Age can be derived from their DateOfBirth.
